Basic Info.
Model NO.
SWT-JRTB3-300
Support Network
GSM
Information content
Data
Certification
CE, ISO, RoHS
Condition
New
Model No.
Swt-Jrtb3-300
Signal of Reception
Bd2 B3
Num Ber of Channels
4 Elements
Anti-Jamming Performance
Three Broadband: 75dB ~ 80dbsingle Broadband: 90dB
Gain of Channel(dB)
40±1
Output Signal Power (dBm)
60±5
Channel Isolation (dB)
≥65
Channel Gain Consistency
≤±1
Power Supply (V)
DC9~DC36
Power Consumption (W)
10(28V/0.36A)
Transport Package
Standard Packing
Trademark
OEM
Origin
Nanjing, China
Production Capacity
30000pices/Year
Product Description
FUNCTION:
Receive BD2-B3 satellite signal, and realize theanti-jamming function of BD2-B3 frequency point satellite signal. TECHNICAL PARAMETERS:
APPLICATION:
Receive BD2-B3 satellite signal, and realize theanti-jamming function of BD2-B3 frequency point satellite signal.
| Signal of reception | BD2 B3 | Power supply (V) | DC9~DC36 |
| Num ber of channels | 4 Elements | Power consumption (W) | 10(28V/0.36A) |
| Anti-jamming performance | Three broadband: 75dB ~ 80dB Single broadband: 90dB ~ 95dB | Weight (kg) | 0.5kg |
| Gain of channel(dB) | 40±1 | Size (mm) | 134 m * 134mm * 20mm (Height without connectors) |
| Output signal power (dBm) | -60±5 | Physical interface | J30J-9 core,SMA-K |
| Channel isolation (dB) | ≥65 | Communication interface | Serial port, TIL level |
| Channel gain consistency | ≤±1 | Operating temperature (°C) | -45~85 |
| Channel gain consistency(°) | ≤±5 | Storage temperature (C) | -55~85 |
| Vibration. shock electromagnetic compatibility, etc | Meet the relevant requirements of GIB |
APPLICATION:
Airborne, vehicle-borne, ship-borne, ground systemsand other application platforms.
Nanjing Shinewave Technology Co., Ltd. is a company specialized in the research and development, production and sales of RF microwave passive components and subsystems. The company's product field covers a variety of microwave communication devices, including microwave filters, duplexers, amplifiers, frequency sources, and related subsystems, which are widely used in mobile communications and other fields.
In terms of microwave filters, the company has comprehensive products and strong design capabilities. The main products include cavity band-stop filter, waveguide filter, electrically tunable filter, multi-frequency combiner, multi-frequency combining platform POI, dielectric cavity dual-mode filter, LC filter, miniaturized comb filter, interdigital filter, etc.
In order to meet the special needs and higher index requirements of customers, in addition to standard products, we provide customized product development methods, and wholeheartedly provide customers with fast and high-quality products and services.
Q&A:
Q1. Could I get a sample before bulk order?
Yes, we offer the sample for all models but charged.
Q2. What should I do if I don't know about frequency in my country?
Please feel free to contact us with your inquiry, we will find the frequency you need and offer help to your problems.
Q3. Do you accept OEM/ODM order?
Yes, we can customize the brand logo, colors, and frequencies.
Q4.Shipment Date
| Sample | 20 business days |
| ≤50 pcs | 60 business days |
| >50 pcs | 90 business days |
| >200 pcs | Negotiate |
Q5: Delivery Date of the sample by DHL/FedEx
| USA/Canada/Europe/Asia | 3-5 days |
| Middle East/Latin American | 5-7 days |
| African | 3-7 days |
